2.6t Tandem Drum Rollers

HIRE THIS ITEM

Master Hire’s 2.6t tandem smooth rollers feature offset drums configuration which is helpful when working close to walls or edges. Often referred to as a CC10 roller, or a double drum roller, they feature an electronic drive lever for smoother starts and stops, which is especially important on asphalt projects.

The tandem smooth roller has a spacious operator station complete with a folding ROPS for optimal all-around machine visibility for safety on the job site. Daily on site maintenance is simple via accessible service and maintenance points and maintenance-free parts. Standard features of this light tandem vibratory roller include front and rear vibration and drive, emergency stop, on board sprinkler system for both drums, 2 working frequencies and a central lifting point and integrated tie down points.

Applications include:

  • Small and medium civil construction sites
  • Asphalt and bitumen compaction
  • Pathways
  • Street repairs
  • Road maintenance

Master Hire’s 2.6t roller trailers are fitted with a standard 50mm quick release ball coupling with electric brakes. These machines can be towed behind any vehicle with an electric brake controller and towing capacity greater than 3500kg.

Product Training and Guidance

Whilst you do not require a licence to operate any of the machines in our tandem drum roller range, should you require additional guidance, Master Hire offers a free customer hand over which includes a thorough walkthrough and training to ensure you can operate the machine confidently and safely at all times.

Delivery and Pick Up

Master Hire offers convenient delivery and pick up options. Speak to our team for delivery rates which may vary depending on location. For more information, or to enquire about our hire rates, contact Master Hire 1300 107 107.

For your safety, convenience and WHS obligations, user manuals and hazard assessments are available for a range of equipment.

Tilt Tray Truck Icon

This item can be transported on the back of a tilt tray truck.

Product Documents

SKU: ROLL2.5S Category: Tags: ,

These specifications are a guide only based on the supplier’s specifications.

Ammann AV26-2 Bomag BW120AD-4 Ammann ARX26
Drum Configuration Double - Smooth Double - Smooth Double - Smooth
Steering Mode Articulated Articulated Articulated
Engine Type Diesel Diesel Diesel
Tank Capacity 40L 40L 40L
Operating Weight 2810kg 2600kg 2530kg
Overall Length 2575mm 2470mm 2369mm
Overall Width 1270mm 1276mm 1334mm
Overall Height 2550mm 2490mm 2550mm
Overall Height ROPS Folded - - 1930mm
Drum Width 1200mm 1200mm 1200mm
Max. Centrifugal Force 41kN 45kN 46.5kN
Frequency 67Hz 70Hz 66Hz
Amplitude 0.4mm 0.52mm 0.5mm
Travel Speed 10km/h 12km/h 10km/h
Gradeability 30/40% 30/40% 30/40%
