Trailer Mounted Traffic Lights


Master Hire’s trailer mounted traffic lights are an important piece of equipment used for traffic control. These solar powered traffic lights have red, yellow and green high visibility LED lanterns. These units come in a dual trailer system allowing a set of two lights to be towed behind one vehicle. Each traffic light set comes with a handheld controller, lead and optional vehicle detection sensors (wireless remotes available on request). Our portable traffic lights can also be programmed and configured into a multi-way modes (4 Way Mimic Mode).. Also available upon request are Stop Here on Red Signal signs.

  • Manual Override Mode
  • Vehicle Trigger Mode (only with optional vehicle detectors)
  • Fixed Time Mode
  • 4 Way Mimic Mode
  • 4 Way Independent Intersection Mode
  • 4 Way Independent Operation
  • Vehicle Trigger 3-Way (only with optional vehicle detectors)
  • Shuttle Mode

Product training and guidance

Our portable traffic lights are easy to use and Master Hire’s free customer hand over includes a thorough walkthrough and equipment training to ensure you can operate the unit safety at all times.

Delivery and Pick Up

Master Hire offers convenient delivery and pick up options. Speak to our team for delivery rates which may vary depending on location. For more information, or to enquire about our hire rates, contact Master Hire 1300 107 107.

For your safety, convenience and WHS obligations, user manuals and hazard assessments are available for a range of equipment.

Towbar Icon

These machines can be towed behind any vehicle with a towing capacity greater than 750kg.

Product Documents

These specifications are a guide only based on the supplier’s specifications.

Bartco PTL Gigasigns PTL-1 Data Signs PTL
Power Source Solar / Battery Solar / Battery Solar / Battery
Lamp Type & Size LED lamps 200mm LED lamps 200mm LED lamps 200mm
ATM (each) 1000kg 895kg 700kg
Stowed Length (set) 3400mm 3870mm 3620mm
Stowed Width 1650mm 1710mm 1400mm
Stowed Height 2165mm 2260mm 2050mm
Operating Length 2200mm (Master) 2200mm (Slave) 2420mm (Master) 1400mm (Slave) 2030mm (Master) 1580mm (Slave)
Operating Width 1650mm 1710mm 1400mm
Operating Height 3015mm 3485mm 2950mm
